XML Policy

Configure XML Security Policy for XML based API web service.

---

Overview

XML Policy is a feature of Haltdos WAF. It allows application owners to block unwanted requests that feature malware XML documents or documents bigger than the allowed size. The owner can set their Minimum & Maximum size limit for the XML document.

How to Use:

1. Log into the Haltdos WAF Professional edition web UI console.
2. Then go to Listeners > Policy > XML Policy.
3. Configure your settings.
4. Click on Save Changes.

Example :

<bookstore>
    <book category="children">
    <title>Harry Potter</title>
    <author>J K. Rowling</author>
    <year>2005</year>
    <price>29.99</price>
    </book>
    <book category="web">
    <title>Learning XML</title>
    <author>Erik T. Ray</author>
    <year>2003</year>
    <price>39.95</price>
    </book>
</bookstore>

Parameters	Accepted value	Default
Supported Header	Drop-Down	Application/xml, text/xml
Maximum Children	Integer	100
Maximum Depth	Integer	100
Maximum Attributes	Integer	100
Maximum Node Name	Integer	1000
Maximum Node Value	Integer	1000
Maximum Attribute Name	Integer	1000
Maximum Attribute value	Integer	1000

Description

Supported Header

Users are allowed to specify supported header i.e. content-type, to identify request as XML.

Maximum Children

This field specifies the maximum child nodes of the XML document. In the above example, Tag <book> has 4 children. An XML document can have a minimum of 1 child and a maximum of 10000 children.

Maximum Depth

This field specifies the maximum depth of an XML document. In the above example, maximum depth is 2, Tag <book> is at depth 1 & children are at depth 2. An XML document can have a minimum depth of 1 and a maximum depth up to 1000000.

Maximum Attributes

This field specifies the maximum attributes for a single node of an XML document. In the above example, the maximum attribute is 1, Tag <book> has 1 attribute. An XML document can have a minimum of 1 attribute and a maximum of 1000 attributes.

Maximum Node Name

This field specifies the maximum node name size of an XML document. In the above example, the maximum node name is 9, Tag <bookstore> length is 9. An XML document can have a minimum of 1 node name size and a maximum of 10000 node name size.

Maximum Node Value

This field specifies the maximum node value of the XML document. In the above example, the maximum node value is 12, Tag <title> has a value of Harry Potter of length 12. An XML document can have a minimum of 1 node value and a maximum of 1000000 node values.

Maximum Attribute Name

This field specifies the maximum attribute name size of an XML document. In the above example, the maximum attribute name is 8, Tag <book> has an attribute category of length 8. An XML document can have a minimum of 1 attribute name and a maximum of 10000 attribute names.

Maximum Attribute Value

This field specifies the maximum attribute value size of the XML document. In the above example, the maximum attribute value is 8, Tag <book> has an attribute category of length 8. An XML document can have a minimum of 1 attribute value and a maximum of 1000000 attribute value.
